Περιγραφή

---

• Operating temperature: max. 150°C (dependent on temperature range of tube/ pipe used)
• Operating pressure: up to 60bar dependent on pressure range of tube/ pipe used and used temperature
• Material: Body and Nut - brass (nickel-plated CW614N and CW617N), Olive - brass polished CW614N, Thread: cyl. thread DIN EN ISO 228 - con. thread DIN EN ISO 10226
• Medium: pneumatic, oil-hydraulic and hydraulic circuits
• Tubes/ pipes: suitable for metal pipes (copper, brass, steel, etc.) and for plastic pipes with inner reinforcement

012-010-0010 012-010-0020 012-010-0030 012-010-0040 012-010-0050 012-010-0060
